Thinkcar Thinktool Euromaster X

Thinkcar Thinktool Euromaster X

THINKTOOL EURO MASTER X is an advanced 10-inch diagnostic tablet that provides OE-level diagnostics and online programming capabilities. The device is designed for a wide range of applications, from passenger car diagnostics to commercial vehicles and trucks, offering support for advanced protocols such as Pass Thru, DoIP, and Can FD.

2-years of updates included in the price!

Thinktool Euro Master X is a professional diagnostic tool for vehicle diagnostics and condition monitoring. The device offers extensive diagnostic coverage of all systems equipped in a vehicle, supporting over 119+ brands and models worldwide, including passenger cars, light commercial vehicles, and hybrid vehicles. The device is continuously updated and expanded with new features through online updates, enhancing its capabilities and diagnostic potential.

1. OE-level diagnostics and online programming

• Full vehicle diagnostics: reading and clearing DTC codes, live data, actuator tests, and bidirectional control.

• Online ECU programming and coding for premium brands (e.g., Audi, BMW, Mercedes-Benz, Porsche, Land Rover, VW).

2. Service functions

• 41 service functions: oil reset, brake reset, steering angle adaptation, battery replacement, TPMS, DPF, AdBlue, EGR, immobilizer, transmission adaptation, injector coding, suspension calibration, window calibration, sunroof calibration, start/stop system, transport mode, odometer adjustment, ECU reset, FRM matching, and many more.

3. Communication and protocols

• Supports DoIP, CAN FD, J2534, D-PDU, and RP1210.

• Wide compatibility with both new and older vehicles.

4. CAN-Bus topology and expansion modules

• Intelligent CAN-Bus network mapping

• Supports additional modules: oscilloscope, thermal camera, battery tester, inspection camera, ADAS, and packages for commercial and electric vehicles.

5. Support and usability

• Supports over 90–300 vehicle brands (passenger and commercial).

• Remote technical support (TeamViewer) and online communication via Wi-Fi.

41 service functions:

EURO MASTER X is equipped with 41 service functions, enabling comprehensive diagnostic procedures, coding, component activation, actuator adjustments, and brand-specific calibrations. These functions include brake system bleeding, adaptive suspension, DPF and EGR module resets, steering angle and TPMS sensor calibration, traction battery diagnostics, as well as ACC radar and ADAS system calibration.

Online Programming

EURO Master X enables advanced online ECU programming for a wide range of brands, including Audi, BMW, Land Rover, Mercedes-Benz, Nissan, Porsche, Seat, Skoda, Subaru, VW, Hyundai, Kia, and more. Compatibility with DoIP, CAN FD, and Pass Thru D-PDU protocols expands its capabilities in modern vehicle diagnostics. The tester allows programming of “virgin” ECUs or updating them to the latest available version.

The diagnostic tester allows unlocking SGW gateways for the following manufacturers:

– FCA Group (Abarth, Alfa Romeo, Chrysler, Dodge, Fiat, Fiat Professional, Jeep, Lancia, RAM i Maserati)

– Renault and Dacia

– Mercedes-Benz

– Grupa VAG (coming soon)

Device equipment:

The set includes:

• Thermal printer that connects to the diagnostic tester
• 10 adapters for vehicles without EOBD

Optional equipment

• Infrared camera module installed in the diagnostic tester housing
• Battery tester in two forms: as a module installed in the tester or as a Bluetooth attachment – ThinkEasy
• 4-channel oscilloscope connected via USB
• LED flashlight adapter that connects to the diagnostic tester
• USB-connected endoscope camera
• 10 adapters for vehicles without EOBD
• IMMO support module (PROG 2)
• TPMS sensor module with Bluetooth communication (T-Wand 200)
• Heavy vehicle module with software and additional cables (HD package)

Technical Specifications:

• Operating System: Android 10
• Processor: 8-core 2.0 GHz
• RAM: 4 GB
• Storage: 128 GB built-in memory
• Display: 10″ touchscreen
• Camera: Rear 8.0 megapixels
• Battery: 12,600 mAh, 3.7 V
• Network: Wi-Fi, WLAN 802.11 b/g/n
• Bluetooth: 5.0

Package Contents:

1. Thinkcar Thinktool Euromaster X diagnostic tester
2. SmartLink diagnostic head
3. Set of cables, connectors, and adapters
4. USB cable with charger
5. Carrying case
6. Card with activation code

Device Interface:
